型號/Model

HY-HCN100 1.7M

HY-HCN100 2.0M

HY-HCN100 2.3M

設備總長/Length

6861mm

設備總寬/Width

2625mm

2925mm

3225mm

設備總高/Height

2184mm

設備凈重/

Net Weight

3900kg

4200kg

4600kg

裁剪高度/

Cutting Height

5/7/11cm(可選/Optional)

刀盤/Cutter Head

1.6/2.0/2.5/3.0mm(可選/Optional)

磨刀方式/

Grinding Mode

雙輪對旋式/Double Round Disrotatory

最高機械速度/

Maximum Speed

60m/min

電源/Power Supply

380V 50Hz

氣流量/Air Flow

160L/min

氣壓/Pressure

≥0.5MPa

最大功率/

Maximum Power

30kW

減速機背隙/

Reducer Backlash

0.05°

再覆蓋/Recover

手動式/氣缸式(選配) Manual/Air Cylinder(Optional)

慣量推定/

Inertia Calcuation

自動調節/Self-adjusting

編碼器位數/

Encoder Bits

20位/23位/24位

20-bit/23-bit/24-bit

安全防撞裝置/Anticollosion Device

光電感應/Optronic Sensor

移動控制方式/Moving Control Mode

無線手柄/wireless controller

導軌安裝/Guide

Rail Installation

整體加工成型安裝/processing and forming installation
